This training addresses all the issues generated by the complexity of IT cabling in buildings and data centers, and allows you to prepare for any new project or renovation. It addresses copper and fiber optic infrastructures, the different architectures as well as performance levels.
Prerequisites
This training requires a basic technical knowledge in cabling and computer network equipment.
Goals
This training responds to all the issues generated by the apparent complexity of building and data center infrastructures, and allows you to prepare for any new construction, renovation, or operation, with the main objectives being sustainability, availability and guaranteed high bandwidth and support for high-speed applications up to 400 Gbps and beyond.
Program
Building and data center topology: backbones and campus, horizontal distribution, patching, interconnection, color coding. Behavior on fire: flame propagation, smoke release, toxicity. The impact of the computer cabling system on the thermal management of computer rooms: overhead cabling, cabling in the raised floor plenum, organization of cabling in computer cabinets. Smart patching.
Copper Cabling
The points covered for copper are:
- Twisted pair technology: shielded technology, with TNS electrical distribution, with TNC electrical distribution, the ground loop.
- Unshielded technology.
- General characteristics: immunity level, bandwidth, Manchester encoding, NRZ, MLT3, PAM5, PAM 16 128 DSQ LDPC.
- Cabling system design: standardization, performance classification, cable naming, connectors, minimum and maximum cable length constraints.
- Installation rules: cable trays, bend radius, traction, distances from high currents, connection of connectors..
- Data center urbanization rules: connection of resources, servers, storage, network.
- Hardware: cabinets, patch panels, pre-connected systems.
- Operation.
- Standardized tests: manufacturer tests, on-site tests, reading of test results.
Fiber optic cabling
The points covered for fiber are:
- General characteristics: immunity, security, bandwidth, the distances, optoelectronic transceivers, financial aspect, comparison copper / optical fiber, design of the cabling system.
- Theory of fiber optic transmission: the index jump, the index gradient, LASER optimized multimode fiber (OM3, OM4 & OM5), single-mode fiber (OS1 & OS2).
- Standardized characteristics of optical fiber cables: attenuation, bandwidth, modal dispersion, polarization dispersion, chromatic dispersion.
- Components: indoor & outdoor cables, connectors, SC, MT-RJ, LC, MTP/MPO connectors, splices, pigtails, hardware, polarity management methods (symmetrical duplex administration & pairs reversed).
- Color codes: cables, connectors, patch panels and interconnections.
- Pre-connected cabling: jumpers, trunks, conversion modules, 3 standardized polarity management schemes.
- Operation: cleaning of the connections, control of the connections, compliance with the bend radius, data center specificities, operator safety.
- Tests: reflectometry, why reflectometry, basic principle, launch fiber, reading a reflectometric trace.
- Photometry: why photometry, the basic principle, the removal of higher modes, reading a photometry test.
- The VFL, Visual Fault Locator.
- Supported applications: Ethernet, Fiber Channel, Infiniband.
- The maximum distances: limitation due to the optical budget; limitation due to insertion loss; limitation due to bandwidth.
- Speeds: 1 Gbps, 10 Gbps, 40 Gbps, 100 Gbps, 400Gbps, 1Tbps
Teaching method
The course is taught by a certified trainer, interactive with the trainees, with corrected exercises and MCQ, Multiple Choice Questionnaire, at the end of the session.
Course materials
The electronic support is updated regularly and includes the course material in French and in English, white papers and related videos.
Certificate
After passing the multiple choice questions, a skills certificate is given to the trainee.
training duration
21 hours over 36 days
